Description
Enclosure: TENV|Frame: 182TC|Max Speed: 9000 rpm|Peak Torque: 60.5 Nm|Rated Torque: 24.60 Nm|Shaft Diameter: 1.125 IN|Speed: 8000 rpm|Agency Approvals: CSA UR|Ambient Temperature: 40 �C|Base Indicator: Rigid|Bearing Grease Type: Polyrex EM|Connection Diagram: CD0006A02|Dimensional Drawing Numbers: 35LYP1160|Duty Rating: CONT|Frame Material: Steel|Frame Suffix: TC|Insulation Class: F|Motor Lead Exit: Front End|Motor Lead Quantity/Wire Size: 3 @ 14 AWG|Mounting Arrangement: F1|Nameplate Output: 3|Nameplate Speed: 900|Output Power: 7.460 KW|Peak Current: 102.0 a|RoHS Status: ROHS COMPLIANT|Rotor Inertia (Servo): .14252|Service Factor: 1.00
