Description
Catalog Number: ECR9204T|Enclosure: TEFC|Frame: 256T|Frame Material: Iron|Frequency: 60.00 Hz|Output @ Frequency: 20.000 HP @ 60 HZ|Phase: 3|Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ|Voltage @ Frequency: 460.0 V @ 60 HZ 230.0 V @ 60 HZ|XP Class and Group: None|XP Division: Not Applicable|Agency Approvals: UR CSA EEV CSA|Ambient Temperature: 40 �C|Auxillary Box: No Auxillary Box|Auxillary Box Lead Termination: None|Base Indicator: Rigid|Bearing Grease Type: Polyrex EM (-20F +300F)|Blower: None|Constant Torque Speed Range: 6|Current @ Voltage: 24.000 A @ 460.0 V 48.000 A @ 230.0 V|Design Code: A|Drip Cover: No Drip Cover|Duty Rating: CONT|Efficiency @ 100% Load: 93.0 %|Electrically Isolated Bearing: Not Electrically Isolated|Feedback Device: NO FEEDBACK|High Voltage Full Load Amps: 24.0 a|Front Face Code: Standard|Front Shaft Indicator: None|Heater Indicator: No Heater|Insulation Class: F|Inverter Code: Inverter Duty|KVA Code: G|Lifting Lugs: Standard Lifting Lugs|Locked Bearing Indicator: Locked Bearing|Max Speed: 2700 rpm|Motor Lead Exit: Ko Box|Motor Lead Termination: Flying Leads|Motor Lead Quantity/Wire Size: 9 @ 10 AWG|Motor Type: 0962M|Mounting Arrangement: F1|Number of Poles: 4|Overall Length: 24.77 IN|Power Factor: 83|Product Family: Super-E Chemical Processing|Pulley End Bearing Type: Ball|Pulley Face Code: Standard|Pulley Shaft Indicator: Standard|Rodent Screen: None|Service Factor: 1.25|Shaft Diameter: 1.625 IN|Shaft Extension Location: Pulley End|Shaft Ground Indicator: No Shaft Grounding|Shaft Rotation: Reversible|Shaft Slinger Indicator: Shaft Slinger|Speed: 1765 rpm|Speed Code: Single Speed|Motor Standards: NEMA|Starting Method: Direct on line|Thermal Device - Bearing: None|Thermal Device - Winding: None|Vibration Sensor Indicator: No Vibration Sensor|Winding Thermal 1: None|Winding Thermal 2: None|Full Load Torque: 0 LB-FT|No-Load Current: 0 A|Line-Line Res. @ 25� C: 0.40887 Ohms A Ph / 0 Ohms B Ph|Temp. Rise @ Rated Load: 61� C|Temp. Rise @ S.F. Load: 78� C|Start Configuration: DOL|Break-Down Torque: 173 LB-FT|Pull-Up Torque: 120 LB-FT|Locked-Rotor Torque: 152 LB-FT|Starting Current: 149 A
