Description
Catalog Number: JMFSWDM41906T-E|Enclosure: TEFC|Frame: 256JM|Frame Material: Stainless Steel|Frequency: 60.00 Hz|Output @ Frequency: 20.000 HP @ 60 HZ|Phase: 3|Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ|Voltage @ Frequency: 460.0 V @ 60 HZ 230.0 V @ 60 HZ|XP Class and Group: None|XP Division: Not Applicable|Agency Approvals: CSA UR|Ambient Temperature: 40 �C|Auxillary Box: No Auxillary Box|Auxillary Box Lead Termination: None|Base Indicator: Rigid|Bearing Grease Type: POLYREX SHC102 EM (-20F +356F)|Blower: None|Current @ Voltage: 23.000 A @ 460.0 V 46.000 A @ 230.0 V|Design Code: A|Drip Cover: No Drip Cover|Duty Rating: CONT|Efficiency @ 100% Load: 91.0 %|Electrically Isolated Bearing: Not Electrically Isolated|Feedback Device: NO FEEDBACK|High Voltage Full Load Amps: 23.0 a|Front Shaft Indicator: None|Heater Indicator: No Heater|Insulation Class: H|Inverter Code: Inverter Duty|KVA Code: K|Lifting Lugs: Standard Lifting Lugs|Locked Bearing Indicator: Locked Bearing|Motor Lead Termination: Flying Leads|Motor Lead Quantity/Wire Size: 9 @ 10 AWG|Motor Type: 3960M|Mounting Arrangement: F1|Number of Poles: 2|Overall Length: 26.68 IN|Power Factor: 90|Product Family: WD All SS Encapsulated|Pulley End Bearing Type: Sealed Bearing|Pulley Face Code: C-Face|Pulley Shaft Indicator: Standard|Rodent Screen: None|RoHS Status: ROHS COMPLIANT|Service Factor: 1.00|Shaft Diameter: 1.250 IN|Shaft Ground Indicator: No Shaft Grounding|Shaft Rotation: Reversible|Shaft Slinger Indicator: No Slinger|Speed: 3540 rpm|Speed Code: Single Speed|Motor Standards: NEMA|Starting Method: Direct on line|Thermal Device - Bearing: None|Thermal Device - Winding: None|Vibration Sensor Indicator: No Vibration Sensor|Winding Thermal 1: None|Winding Thermal 2: None|Full Load Torque: 0 LB-FT|No-Load Current: 0 A|Line-Line Res. @ 25� C: 0.30935 Ohms A Ph / 0 Ohms B Ph|Temp. Rise @ Rated Load: 85� C|Temp. Rise @ S.F. Load: |Start Configuration: DOL|Break-Down Torque: 161 LB-FT|Pull-Up Torque: 64.7 LB-FT|Locked-Rotor Torque: 78.2 LB-FT|Starting Current: 221 A
