Baldor-Reliance M3463 .75HP, 3450RPM, 3PH, 60HZ, 48, 3413M, TEFC, F1

Baldor-Reliance
No reviews yet Write a Review
$711.98
SKU:
DZ88YG
UPC:
781568101940
MPN:
M3463
Shipping:
Calculated at Checkout
In Stock & Ready To Ship!
Availability: If required, please call 562/945-1289 to confirm availability. If for any reason, the product you ordered cannot be delivered within 5 days - we will communicate with you immediately via phone & email.
Current Stock:Only left:

Frequently Bought Together:

Total: Inc. Tax
Total: Ex. Tax

Description

Catalog Number: M3463|Enclosure: TEFC|Frame: 48|Frame Material: Steel|Frequency: 60.00 Hz|Output @ Frequency: .750 HP @ 60 HZ|Phase: 3|Synchronous Speed @ Frequency: 3600 RPM @ 60 HZ|Voltage @ Frequency: 460.0 V @ 60 HZ 230.0 V @ 60 HZ|XP Class and Group: None|XP Division: Not Applicable|Agency Approvals: CSA UR|Ambient Temperature: 40 �C|Auxillary Box: No Auxillary Box|Auxillary Box Lead Termination: None|Base Indicator: Rigid|Bearing Grease Type: Polyrex EM (-20F +300F)|Blower: None|Current @ Voltage: 1.300 A @ 460.0 V 2.600 A @ 230.0 V 3.100 A @ 208.0 V|Design Code: B|Drip Cover: No Drip Cover|Duty Rating: CONT|Efficiency @ 100% Load: 74.0 %|Electrically Isolated Bearing: Not Electrically Isolated|Feedback Device: NO FEEDBACK|High Voltage Full Load Amps: 1.3 a|Front Face Code: Standard|Front Shaft Indicator: None|Heater Indicator: No Heater|Insulation Class: B|Inverter Code: Not Inverter|KVA Code: K|Lifting Lugs: No Lifting Lugs|Locked Bearing Indicator: No Locked Bearing|Motor Lead Exit: Ko Box|Motor Lead Termination: Flying Leads|Motor Lead Quantity/Wire Size: 9 @ 18 AWG|Motor Type: 3413M|Mounting Arrangement: F1|Number of Poles: 2|Overall Length: 10.73 IN|Power Factor: 73|Product Family: General Purpose|Pulley End Bearing Type: Ball|Pulley Face Code: Standard|Pulley Shaft Indicator: Standard|Rodent Screen: None|Service Factor: 1.25|Shaft Diameter: 0.500 IN|Shaft Extension Location: Pulley End|Shaft Ground Indicator: No Shaft Grounding|Shaft Rotation: Reversible|Shaft Slinger Indicator: No Slinger|Speed: 3450 rpm|Speed Code: Single Speed|Motor Standards: NEMA|Starting Method: Direct on line|Thermal Device - Bearing: None|Thermal Device - Winding: None|Vibration Sensor Indicator: No Vibration Sensor|Winding Thermal 1: None|Winding Thermal 2: None|Full Load Torque: 0 LB-FT|No-Load Current: 0 A|Line-Line Res. @ 25� C: 24.6 Ohms A Ph / 0 Ohms B Ph|Temp. Rise @ Rated Load: 64� C|Temp. Rise @ S.F. Load: 84� C|Start Configuration: DOL|Break-Down Torque: 4.8 LB-FT|Pull-Up Torque: 3.5 LB-FT|Locked-Rotor Torque: 3.9 LB-FT|Starting Current: 7.6 A

Warranty

Monarch Bearing Co. offers a 30-day Return Policy on every item we sell. Please see Terms of Sale & Return Policy for more specific details.
