Description
Catalog Number: MM13754-PP|Frame: 132|Frame Material: Cast Iron|Frequency: 50.00 Hz 60.00 Hz|Output @ Frequency: 7.50 KW @ 50 HZ 7.50 KW @ 60 HZ|Phase: 3|Synchronous Speed @ Frequency: 1500 RPM @ 50 HZ|Voltage @ Frequency: 400 V @ 50 HZ 460 V @ 60 HZ 690 V @ 50 HZ|Ambient Temperature: 40 �C|Auxillary Box: Top|Current @ Voltage: 12.70 A @ 460 V 14.50 A @ 400 V 8.41 A @ 690 V|Duty Rating: S1|Efficiency @ 100% Load: 88.7 %|Efficiency @ 50% Load: 90.5 %|Efficiency @ 75% Load: 9.0 %|High Voltage Full Load Amps: 8.4 a|Insulation Class: F|IP Rating: IP55|Number of Poles: 4|Power Factor: .83|Product Family: Process Performance|Rotor Inertia: 0.03659 lb-ft2|Speed: 1450 rpm 1760 rpm|Speed Code: Single Speed|Motor Standards: IEC
Warranty
Monarch Bearing Co. offers a 30-day Return Policy on every item we sell. Please see Terms of Sale & Return Policy for more specific details.
