Description
Catalog Number: MM28752-PP|Enclosure: TEFC|Frame: 280|Frame Material: Cast Iron|Frequency: 50.00 Hz|Output @ Frequency: 75.00 KW @ 50 HZ|Phase: 3|Synchronous Speed @ Frequency: 3000 RPM @ 50 HZ|Voltage @ Frequency: 690 V @ 50 HZ 415 V @ 50 HZ 400 V @ 50 HZ|Ambient Temperature: 40 �C|Auxillary Box: Top|CE: CE|Current @ Voltage: 128.00 A @ 415 V 131.00 A @ 400 V 76.60 A @ 690 V|Duty Rating: S1|Efficiency @ 100% Load: 94.4 %|Efficiency @ 50% Load: 92.6 %|Efficiency @ 75% Load: 9.4 %|High Voltage Full Load Amps: 76.6 a|Insulation Class: F|IP Rating: IP55|Number of Poles: 2|Power Factor: .87|Product Family: Process Performance|PTC Thermistor Conn Diagram: 3GZF321200-1D|Rotor Inertia: 0.00008 lb-ft2|Speed: 2977 rpm 2978 rpm 2980 rpm|Speed Code: Single Speed|Motor Standards: IEC
