Description
Catalog Number: ZDFRPM21254C|Enclosure: TEFC|Frame: FL2162C|Frame Material: Exposed Laminations|Frequency: 60.00 Hz|Output @ Frequency: 25.000 HP @ 60 HZ|Phase: 3|Synchronous Speed @ Frequency: 1800 RPM @ 60 HZ|Voltage @ Frequency: 460.0 V @ 60 HZ|Agency Approvals: CCSA US UR|Auxillary Box: No Auxillary Box|Base Indicator: Rigid|Bearing Grease Type: No Grease|Current @ Voltage: 34.000 A @ 460.0 V|Duty Rating: CONT|Feedback Device: ENCODER|High Voltage Full Load Amps: 34.0 a|Frame Prefix: FL|Heater Indicator: No Heater|Insulation Class: H|Mounting Arrangement: F3|Overall Length: 31.56 IN|Product Family: General Industrial|Pulley End Bearing Type: Ball|Pulley Face Code: C-Face|Service Factor: 1.00|Shaft Diameter: 1.625 IN|Shaft Ground Indicator: No Shaft Grounding|Shaft Rotation: Reversible|Speed: 1780 rpm|Motor Standards: NEMA|Thermal Device - Bearing: None|Thermal Device - Winding: Normally Closed Thermostat
